| Uimhir Pháirt | B116XTN02.5 |
| Branda | AUO |
| Méid | 11.6 |
| Iarratas | Laptop Netbook PC |
| Rún | 1366×768 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 400:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | eDP |
| monaróir | AUO |
| méid scáileáin | 11.6 inch |
| uimhir picteilín | 1366(RGB)×768 (WXGA) 135PPI |
| limistéar gníomhach(mm) | 256.125 × 144 (H×V) |
| limistéar bezel (mm) | - |
| luminance | 250 cd/m² (Typ.) |
| uillinn féachana | 45/45/15/35 (Typ.)(CR≥10) |
| radharc maith ag | 6 o'clock |
| doimhneacht dath | 262K 45% NTSC |
| cruth imlíne | Slim (PCBA Flat, T≤3.2mm) |
| ráta athnuachana | 60Hz |
| cineál comhartha | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| ainm samhail | B116XTN02.5 (AUO255C) |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 278 × 168 × 3 (H×V×D) |
| cóireáil | Antiglare |
| cóimheas codarsnachta | 400 : 1 (Typ.) (TM) |
| freagra | 8 (Typ.)(Tr+Td) ms |
| modh oibre | TN, Normally White, Transmissive |
| cúlsolas | WLED , 15K hours , With LED Driver |
| a úsáidtear le haghaidh | Laptop Netbook PC |
| scáileán tadhaill | Without |
