| Uimhir Pháirt | B080EAK02.2 |
| Branda | AUO |
| Méid | 8.0 |
| Iarratas | Pad & Tablet |
| Rún | 800×1280 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 900:1 |
| Dathanna | 16.7M |
| Cúlsolas | 4S5P |
| Comhéadan | MIPI |
| branda painéil | AUO |
| múnla painéil | B080EAK02.2 |
| méid an phainéil | 8.0" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 800(RGB)×1280, WXGA, 188PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 107.64(W)×172.224(H) mm |
| oscailt bezel | - |
| méid imlíne | 113.72(W)×183.764(H) ×4.1(D) mm |
| dromchla | Glare (Haze 0%) |
| gile | 360 cd/m² (Typ.) |
| cóimheas codarsnachta | 900:1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| mód taispeána | AHVA, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 25 (Typ.)(Tr+Tf) |
| dathanna a thaispeáint | 16.7M 58% NTSC |
| cineál lampa | 4S5P WLED , 15K hours , Without Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | 120g (Max.) |
| iarratas | Pad & Tablet |
| comhéadan comhartha | MIPI (4 data lanes) , 39 pins Connector |
| voltas ionchuir | 1.8/3.3V (Typ.)(VCC1/VC2) |
| timpeallacht | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
