| Uimhir Pháirt | AV123Z7T-A19-D8P0 |
| Branda | BOE |
| Méid | 12.3 |
| Iarratas | Outdoor High Brightn |
| Rún | 1920×720 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 1100:1 |
| Dathanna | 16.7M |
| Cúlsolas | 9S4P |
| Comhéadan | LVDS |
| monaróir | BOE |
| ainm samhail | AV123Z7T-A19-D8P0 |
| méid scáileáin | 12.3 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 1920(RGB)×720 167PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 292.032 × 109.512 (H×V) |
| imlíne (mm) | 345.19 × 149.1 × 27.93 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Anti Fingerprint + Antiglare, Hard coating (3H) |
| luminance | 850 cd/m² (Typ.) |
| cóimheas codarsnachta | 1100 : 1 (Typ.) (TM) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| freagra | 25 (Max.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | IPS, Normally Black, Transmissive |
| doimhneacht dath | 16.7M 80% NTSC |
| cúlsolas | 9S4P WLED , 50K hours , No Driver |
| mais | - |
| a úsáidtear le haghaidh | Outdoor High Brightness Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | PCAP |
| cineál comhartha | LVDS (2 ch, 8-bit) , Connector 60 pins |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
