| Uimhir Pháirt | AT070MP11 |
| Branda | Mitsubishi |
| Méid | 7.0 |
| Iarratas | Industrial Outdoor H |
| Rún | 800×480 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| monaróir | Mitsubishi |
| ainm samhail | AT070MP11 |
| méid scáileáin | 7.0 inch |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| uimhir picteilín | 800(RGB)×480 (WVGA) 133PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 152.4 × 91.44 (H×V) |
| imlíne (mm) | 169.8 × 109.7 × 9.4 (H×V×D) |
| limistéar bezel (mm) | 154.4 × 93.5 (H×V) |
| cóireáil | Antiglare, Hard coating (3H) |
| luminance | 1300 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 4/12 (Typ.)(Tr/Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | SWV, Normally Black, Transmissive |
| doimhneacht dath | 262K/16.7M 50% NTSC |
| cúlsolas | WLED , 100K hours , No Driver |
| mais | 200g |
| a úsáidtear le haghaidh | Industrial Outdoor High Brightness Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
