| Uimhir Pháirt | AMSA05BV09 |
| Branda | SAMSUNG |
| Méid | 10.5 |
| Iarratas | Pad & Tablet |
| Rún | 2560×1600 |
| Comhdhéanamh | AM-OLED, OLED |
| Gile | |
| CR | 54000:1 |
| Dathanna | 16.7M |
| Cúlsolas | self |
| Comhéadan | MIPI |
| branda painéil | SAMSUNG |
| múnla painéil | AMSA05BV09 |
| méid an phainéil | 10.5" |
| cineál painéil | AM-OLED, OLED |
| taifeach | 2560(RGB)×1600, 287PPI |
| formáid picteilín | S-Stripe RGB |
| limistéar taispeána | 226.56(W)×141.6(H) mm |
| oscailt bezel | - |
| méid imlíne | 251.4(W)×171.1(H) mm |
| dromchla | - |
| gile | 300 cd/m² (Typ.) |
| cóimheas codarsnachta | 54000:1 (Min.) (TM) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥200) |
| mód taispeána | - |
| radharc is fearr ar | Symmetry |
| am freagartha | - |
| dathanna a thaispeáint | 16.7M 100% NTSC |
| cineál lampa | self |
| minicíocht | 60Hz |
| scáileán tadhaill | PCAP |
| Tiománaí ic | COG Built-in EA8002ASA |
| meáchan painéal | 143/148g (Typ./Max.) |
| iarratas | Pad & Tablet |
| comhéadan comhartha | MIPI (2 ch, 4 data lanes) , 80 pins Connector |
| voltas ionchuir | 1.8/3.3/3.8V (Typ.)(VDD1/VDD3/VBAT) |
| timpeallacht | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
