| Uimhir Pháirt | AM800480R3TMQW-B2H |
| Branda | AMPIRE |
| Méid | 7.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 400:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | AMPIRE |
| Mionsamhail | AM800480R3TMQW-B2H |
| méid trasnánach | 7.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 800(RGB)×480 [WVGA] 133PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 152.4(H)×91.44(V) mm |
| imlíne dim. | - |
| luminance | - |
| cóimheas codarsnachta | 400:1 (Typ.) (TM) |
| treo amharc | 6 o'clock |
| am freagartha | 5/11 (Typ.)(Tr/Td) |
| uillinn féachana | 70/70/60/70 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 262K 45% NTSC |
| foinse solais | WLED |
| meáchan | - |
| deartha le haghaidh | Industrial |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 8-bit) , 20 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
