| Uimhir Pháirt | AM-800600MTMQW-50H |
| Branda | AMPIRE |
| Méid | 8.4 |
| Iarratas | Industrial Outdoor H |
| Rún | 800×600 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 600:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | 6S5P |
| Comhéadan | |
| branda painéil | AMPIRE |
| méid an phainéil | 8.4" |
| taifeach | 800(RGB)×600, SVGA, 119PPI |
| limistéar taispeána | 170.4(W)×127.8(H) mm |
| méid imlíne | 189.75(W)×149.4(H) ×5.3(D) mm |
| gile | 1000 cd/m² (Typ.) |
| uillinn féachana | 75/75/60/70 (Typ.)(CR≥10) |
| radharc is fearr ar | - |
| dathanna a thaispeáint | 262K/16.7M |
| minicíocht | 60Hz |
| meáchan | TBD |
| múnla painéil | AM-800600MTMQW-50H |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 173.4(W)×130.8(H) mm |
| dromchla | - |
| cóimheas codarsnachta | 600:1 (Typ.) (TM) |
| mód taispeána | TN, Normally White, Transmissive |
| am freagartha | 8 (Typ.)(Tr+Td) |
| cineál lampa | 6S5P WLED , Without Driver |
| scáileán tadhaill | Without |
| iarratas | Industrial Outdoor High Brightness |
| AA084SA01 | Mitsubishi | 8.4 | 800×600 |
| AM-800600M3TNQW-00H | AMPIRE | 8.4 | 800×600 |
| AM-800600M3TNQW-01H-F | AMPIRE | 8.4 | 800×600 |
| G084SN05 V3 | AUO | 8.4 | 800×600 |
| G084SN05 V7 | AUO | 8.4 | 800×600 |
| LQ084S3LG03 | SHARP | 8.4 | 800×600 |
| LTA084C190F | TOSHIBA | 8.4 | 800×600 |
| LTA084C274F | TOSHIBA | 8.4 | 800×600 |
| NL6448BC26-08D | NLT | 8.4 | 640×480 |
| NL6448BC26-09C | NLT | 8.4 | 640×480 |
