| Uimhir Pháirt | AM-800600MGTMQW-02H |
| Branda | AMPIRE |
| Méid | 8.4 |
| Iarratas | Industrial |
| Rún | 800×600 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 600:1 |
| Dathanna | 16.7M |
| Cúlsolas | 12S4P |
| Comhéadan | LVDS |
| branda painéil | AMPIRE |
| múnla painéil | AM-800600MGTMQW-02H |
| méid an phainéil | 8.4" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 800(RGB)×600, SVGA, 119PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 170.4(W)×127.8(H) mm |
| oscailt bezel | 174.15(W)×131.2(H) mm |
| méid imlíne | 203(W)×145.5(H) ×11.7(D) mm |
| dromchla | - |
| gile | 350 cd/m² (Typ.) |
| cóimheas codarsnachta | 600:1 (Typ.) (TM) |
| uillinn féachana | 75/75/60/70 (Typ.)(CR≥10) |
| mód taispeána | TN, Normally White, Transmissive |
| radharc is fearr ar | - |
| am freagartha | 8 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 16.7M |
| cineál lampa | 12S4P WLED , 50K hours , With LED Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | TBD |
| iarratas | Industrial |
| comhéadan comhartha | LVDS (1 ch, 8-bit) , 20 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| AA084SD01 | Mitsubishi | 8.4 | 800×600 |
| AA084XE11 | Mitsubishi | 8.4 | 1024×768 |
| AM-800600M3TNQW-00H | AMPIRE | 8.4 | 800×600 |
| AM-800600M3TNQW-01H-F | AMPIRE | 8.4 | 800×600 |
| LQ9D023 | SHARP | 8.4 | 640×480 |
| LTA084C270F | TOSHIBA | 8.4 | 800×600 |
| LTM08C343S | TOSHIBA | 8.4 | 800×600 |
| NL6448BC26-01 | NLT | 8.4 | 640×480 |
| NL6448BC26-15 | NLT | 8.4 | 640×480 |
| TM084SDHG50 | Tianma | 8.4 | 800×600 |
