| Uimhir Pháirt | AM-800600K2TMQW-04H |
| Branda | AMPIRE |
| Méid | 10.4 |
| Iarratas | Industrial |
| Rún | 800×600 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | AMPIRE |
| méid an phainéil | 10.4" |
| taifeach | 800(RGB)×600, SVGA, 96PPI |
| limistéar taispeána | 211.2(W)×158.4(H) mm |
| méid imlíne | 243(W)×185.6(H) mm |
| gile | 500 cd/m² (Typ.) |
| uillinn féachana | 70/70/50/60 (Typ.)(CR≥10) |
| radharc is fearr ar | 6 o'clock |
| dathanna a thaispeáint | 262K 50% NTSC |
| minicíocht | 60Hz |
| meáchan painéal | - |
| comhéadan comhartha | LVDS (1 ch, 6-bit) , 20 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -35 ~ 85 °C |
| múnla painéil | AM-800600K2TMQW-04H |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 214.8(W)×162.7(H) mm |
| dromchla | - |
| cóimheas codarsnachta | 500:1 (Typ.) (TM) |
| mód taispeána | TN, Normally White, Transmissive |
| am freagartha | 5/15 (Typ.)(Tr/Td) |
| cineál lampa | WLED , 30K hours , With LED Driver |
| scáileán tadhaill | Without |
| iarratas | Industrial |
