| Uimhir Pháirt | AM-800480R2TMQW-U0H |
| Branda | AMPIRE |
| Méid | 7.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 250:1 |
| Dathanna | 65K |
| Cúlsolas | WLED |
| Comhéadan | UART |
| monaróir | AMPIRE |
| ainm samhail | AM-800480R2TMQW-U0H |
| méid scáileáin | 7.0 inch |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| uimhir picteilín | 800(RGB)×480 (WVGA) 133PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 152.4 × 91.44 (H×V) |
| imlíne (mm) | 178.5 × 110 × 20.4 (H×V×D) |
| limistéar bezel (mm) | 155.3 × 94.3 (H×V) |
| cóireáil | - |
| luminance | 400 cd/m² (Typ.) |
| cóimheas codarsnachta | 250 : 1 (Typ.) (TM) |
| uillinn féachana | 70/70/60/60 (Typ.)(CR≥10) |
| freagra | 50 (Typ.)(Tr+Td) ms |
| radharc maith ag | - |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 65K 48% NTSC |
| cúlsolas | WLED , With LED Driver |
| mais | - |
| a úsáidtear le haghaidh | Industrial |
| ráta athnuachana | - |
| scáileán tadhaill | Without |
| cineál comhartha | UART , 8 pins Connector |
| soláthar voltais | 4.6/26.0V (Min./Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AM-800480-050D | Other | 5.0 | 800×480 |
| AM-800480LATMQW-TN0H | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-00H-F | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| AM-800480R3TMQW-B2H | AMPIRE | 7.0 | 800×480 |
| AM-800480RCTMQW-00H | AMPIRE | 7.0 | 800×480 |
| AM-800480RSTMQW-TA1H | AMPIRE | 7.0 | 800×480 |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-00 | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-W0 | AMPIRE | 7.0 | 800×480 |
