| Uimhir Pháirt | AM-800480N3TZQW-57H |
| Branda | AMPIRE |
| Méid | 5.0 |
| Iarratas | Industrial Automotiv |
| Rún | 800×480 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 262K |
| Cúlsolas | 3S6P |
| Comhéadan | |
| monaróir | AMPIRE |
| ainm samhail | AM-800480N3TZQW-57H |
| méid scáileáin | 5.0 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 800(RGB)×480 (WVGA) 188PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 108 × 64.8 (H×V) |
| imlíne (mm) | 119.7 × 78.3 × 10.05 (H×V×D) |
| limistéar bezel (mm) | 109.6 × 66.4 (H×V) |
| cóireáil | - |
| luminance | 1000 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 30 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | IPS, Normally Black, Transmissive |
| doimhneacht dath | 262K |
| cúlsolas | 3S6P WLED , 50K hours , With LED Driver |
| mais | - |
| a úsáidtear le haghaidh | Industrial Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
