| Uimhir Pháirt | AM-800480LTMQW-WAH |
| Branda | AMPIRE |
| Méid | 5.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | CPU |
| branda | AMPIRE |
| Mionsamhail | AM-800480LTMQW-WAH |
| méid trasnánach | 5.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 800(RGB)×480 [WVGA] 188PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 108(H)×64.8(V) mm |
| imlíne dim. | 118.5(H)×77.1(V) ×6.37(D) mm |
| limistéar bezel | 110.6(H)×67.4(V) mm |
| cóireáil | - |
| luminance | 470 cd/m² (Typ.) |
| cóimheas codarsnachta | 500:1 (Typ.) (TM) |
| treo amharc | - |
| am freagartha | 15/35 (Typ.)(Tr/Td) |
| uillinn féachana | 70/70/70/50 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 262K 52% NTSC |
| foinse solais | WLED [3S6P] , With LED Driver |
| meáchan | TBD |
| deartha le haghaidh | Industrial |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | CPU , 40 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AM-800480-050D | Other | 5.0 | 800×480 |
| AM-800480LATMQW-TN0H | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-00H-F | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| AM-800480R3TMQW-B2H | AMPIRE | 7.0 | 800×480 |
| AM-800480RCTMQW-00H | AMPIRE | 7.0 | 800×480 |
| AM-800480RSTMQW-TA1H | AMPIRE | 7.0 | 800×480 |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-00 | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-W0 | AMPIRE | 7.0 | 800×480 |
