| Uimhir Pháirt | AM-800480LATMQW-TN0H-L |
| Branda | AMPIRE |
| Méid | 5.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 250:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | Parallel |
| branda | AMPIRE |
| méid trasnánach | 5.0 inch |
| formáid picteilín | 800(RGB)×480 [WVGA] 188PPI |
| limistéar gníomhach | 108(H)×64.8(V) mm |
| luminance | 360 cd/m² (Typ.) |
| treo amharc | - |
| uillinn féachana | 70/70/70/50 (Typ.)(CR≥10) |
| dath tacaíochta | 16.7M 52% NTSC |
| meáchan | - |
| ráta fhráma | 60Hz |
| cineál comhéadan | Parallel RGB (1 ch, 8-bit) , 45 pins FPC |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| Mionsamhail | AM-800480LATMQW-TN0H-L |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 118.5(H)×74(V) ×5.16(D) mm |
| cóimheas codarsnachta | 250:1 (Typ.) (TM) |
| am freagartha | 15/35 (Max.)(Tr/Td) |
| modh oibriúcháin | TN, Normally White, Transflective |
| foinse solais | WLED [3S6P] , W/O Driver |
| deartha le haghaidh | Industrial |
| painéal tadhaill | PCAP |
