| Uimhir Pháirt | AM-800480L6TZQW-TN0H-I |
| Branda | AMPIRE |
| Méid | 5.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 250:1 |
| Dathanna | 16.7M |
| Cúlsolas | 3S4P |
| Comhéadan | Parallel |
| monaróir | AMPIRE |
| ainm samhail | AM-800480L6TZQW-TN0H-I |
| méid scáileáin | 5.0 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 800(RGB)×480 (WVGA) 188PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 108 × 64.8 (H×V) |
| imlíne (mm) | 118.5 × 77.1 × 6.44 (H×V×D) |
| limistéar bezel (mm) | 110.6 × 67.4 (H×V) |
| cóireáil | - |
| luminance | 500 cd/m² (Typ.) |
| cóimheas codarsnachta | 250 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 15/35 (Typ.)(Tr/Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | Normally Black, Transmissive |
| doimhneacht dath | 16.7M 52% NTSC |
| cúlsolas | 3S4P WLED , 30K hours , No Driver |
| mais | - |
| a úsáidtear le haghaidh | Industrial |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | PCAP |
| cineál comhartha | Parallel RGB (1 ch, 8-bit) , FPC 45 pins |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AMS495QA01 | Samsung | 5.0 | 960×544 |
| CLAF050LN41 TXX | CPT | 5.0 | 540×960 |
| EE050NA-04A | Innolux | 5.0 | 640×480 |
| LM050QC1T01 | SHARP | 5.0 | 320×240 |
| LMS501KF03 | Samsung | 5.0 | 480×800 |
| LQ050A5BS02 | SHARP | 5.0 | 320×234 |
| LQ050W1LA0A | SHARP | 5.0 | 1024×600 |
| LQ5AW136T | SHARP | 5.0 | 320×234 |
| LS050T1SX01 | SHARP | 5.0 | 1080×1920 |
| TFD50W72MS | TOSHIBA | 5.0 |
