| Uimhir Pháirt | AM-800480D1TMQW-00H |
| Branda | AMPIRE |
| Méid | 8.0 |
| Iarratas | Industrial Automotiv |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda | AMPIRE |
| Mionsamhail | AM-800480D1TMQW-00H |
| méid trasnánach | 8.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 800(RGB)×480 [WVGA] 116PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 176.64(H)×99.36(V) mm |
| imlíne dim. | 192.8(H)×116.9(V) ×6.7(D) mm |
| limistéar bezel | 180.1(H)×103.4(V) mm |
| cóireáil | Antiglare |
| luminance | 450 cd/m² (Typ.) |
| cóimheas codarsnachta | 500:1 (Typ.) (TM) |
| treo amharc | - |
| am freagartha | 10/15 (Typ.)(Tr/Td) |
| uillinn féachana | 70/70/50/70 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 262K/16.7M |
| foinse solais | WLED , 20K hours , W/O Driver |
| meáchan | 251g (Typ.) |
| deartha le haghaidh | Industrial Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
