| Uimhir Pháirt | AM-800480CTZQW-A5H |
| Branda | AMPIRE |
| Méid | 7.0 |
| Iarratas | Industrial Outdoor H |
| Rún | 800×480 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 262K |
| Cúlsolas | 6S5P |
| Comhéadan | LVDS |
| monaróir | AMPIRE |
| ainm samhail | AM-800480CTZQW-A5H |
| méid scáileáin | 7.0 inch |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| uimhir picteilín | 800(RGB)×480 (WVGA) 133PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 152.4 × 91.44 (H×V) |
| imlíne (mm) | 165 × 104.4 × 11.61 (H×V×D) |
| limistéar bezel (mm) | 15.48 × 93.85 (H×V) |
| cóireáil | - |
| luminance | 1500 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| freagra | 25 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | IPS, Normally Black, Transmissive |
| doimhneacht dath | 262K 58% NTSC |
| cúlsolas | 6S5P WLED , 50K hours , With LED Driver |
| mais | - |
| a úsáidtear le haghaidh | Industrial Outdoor High Brightness |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | LVDS (1 ch, 6-bit) , 20 pins Connector |
| soláthar voltais | 12.0V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
