| Uimhir Pháirt | AM-800480AZTMQW-50H |
| Branda | AMPIRE |
| Méid | 5.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 600:1 |
| Dathanna | 16.7M |
| Cúlsolas | 3S6P |
| Comhéadan | |
| branda painéil | AMPIRE |
| méid an phainéil | 5.0" |
| taifeach | 800(RGB)×480, WVGA, 188PPI |
| limistéar taispeána | 108(W)×64.8(H) mm |
| méid imlíne | 119.7(W)×78(H) ×6.1(D) mm |
| gile | 1000 cd/m² (Typ.) |
| uillinn féachana | 75/75/70/60 (Typ.)(CR≥10) |
| radharc is fearr ar | - |
| dathanna a thaispeáint | 16.7M 47% NTSC |
| minicíocht | 60Hz |
| meáchan | - |
| múnla painéil | AM-800480AZTMQW-50H |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | - |
| dromchla | Antiglare |
| cóimheas codarsnachta | 600:1 (Typ.) (TM) |
| mód taispeána | TN, Normally White, Transmissive |
| am freagartha | 2/6 (Typ.)(Tr/Td) |
| cineál lampa | 3S6P WLED , 50K hours , Without Driver |
| scáileán tadhaill | Without |
| iarratas | Industrial |
