| Uimhir Pháirt | AM-800480AZTMQW-05H |
| Branda | AMPIRE |
| Méid | 5.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 600:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | |
| branda | AMPIRE |
| Mionsamhail | AM-800480AZTMQW-05H |
| méid trasnánach | 5.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 800(RGB)×480 [WVGA] 188PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 108(H)×64.8(V) mm |
| imlíne dim. | 118.5(H)×77.1(V) ×7.41(D) mm |
| limistéar bezel | 110.6(H)×67.4(V) mm |
| cóireáil | - |
| luminance | 500 cd/m² (Typ.) |
| cóimheas codarsnachta | 600:1 (Typ.) (TM) |
| treo amharc | - |
| am freagartha | 2/6 (Typ.)(Tr/Td) |
| uillinn féachana | 75/75/70/60 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 262K 47% NTSC |
| foinse solais | WLED [3S7P] , 30K hours , With LED Driver |
| meáchan | - |
| deartha le haghaidh | Industrial |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
