| Uimhir Pháirt | AM-640480VTZQW-00H |
| Branda | AMPIRE |
| Méid | 5.7 |
| Iarratas | Industrial |
| Rún | 640×480 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1200:1 |
| Dathanna | 262K |
| Cúlsolas | 4S7P |
| Comhéadan | CMOS |
| branda painéil | AMPIRE |
| méid an phainéil | 5.7" |
| taifeach | 640(RGB)×480, VGA, 141PPI |
| limistéar taispeána | 115.2(W)×86.4(H) mm |
| méid imlíne | 127(W)×98.43(H) ×6.9(D) mm |
| gile | 500 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 262K 63% NTSC |
| minicíocht | 60Hz |
| meáchan painéal | - |
| comhéadan comhartha | CMOS (1 ch, 6-bit) , 40 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| múnla painéil | AM-640480VTZQW-00H |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 118.0(W)×89.2(H) mm |
| dromchla | - |
| cóimheas codarsnachta | 1200:1 (Typ.) (TM) |
| mód taispeána | IPS, Normally Black, Transmissive |
| am freagartha | 30 (Typ.)(Tr+Td) |
| cineál lampa | 4S7P WLED , 50K hours , With LED Driver |
| scáileán tadhaill | Without |
| iarratas | Industrial |
| AM-640480G2TNQW-00H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-A0H | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-T01H | AMPIRE | 5.7 | 640×480 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| AM-640480GJTNQW-TA0H | AMPIRE | 5.7 | 640×480 |
| LQ057AC111 | Other | 5.7 | 320×240 |
| TM057QDH01 | Tianma | 5.7 | 640×480 |
