| Uimhir Pháirt | AM-640480GJTNQW-TA2H |
| Branda | AMPIRE |
| Méid | 5.7 |
| Iarratas | Industrial |
| Rún | 640×480 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 250:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | AMPIRE |
| múnla painéil | AM-640480GJTNQW-TA2H |
| méid an phainéil | 5.7" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 640(RGB)×480, VGA, 141PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 115.2(W)×86.4(H) mm |
| oscailt bezel | - |
| méid imlíne | 127(W)×98.43(H) ×10.88(D) mm |
| dromchla | - |
| gile | 425 cd/m² (Typ.) |
| cóimheas codarsnachta | 250:1 (Typ.) (TM) |
| uillinn féachana | 70/70/50/50 (Typ.)(CR≥10) |
| mód taispeána | TN, Normally White, Transmissive |
| radharc is fearr ar | - |
| am freagartha | 50 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 262K 50% NTSC |
| cineál lampa | WLED , 20K hours , With LED Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | PCAP |
| meáchan painéal | - |
| iarratas | Industrial |
| comhéadan comhartha | LVDS (1 ch, 8-bit) , 20 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
