| Uimhir Pháirt | AM-640480G2TNQW-T08H |
| Branda | AMPIRE |
| Méid | 5.7 |
| Iarratas | Industrial |
| Rún | 640×480 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 250:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | Parallel |
| monaróir | AMPIRE |
| ainm samhail | AM-640480G2TNQW-T08H |
| méid scáileáin | 5.7 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 640(RGB)×480 (VGA) 141PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 115.2 × 86.4 (H×V) |
| imlíne (mm) | 127 × 98.43 × 10.2 (H×V×D) |
| limistéar bezel (mm) | 118.0 × 89.2 (H×V) |
| cóireáil | - |
| luminance | 200 cd/m² (Typ.) |
| cóimheas codarsnachta | 250 : 1 (Typ.) (TM) |
| uillinn féachana | 70/70/50/50 (Typ.)(CR≥10) |
| freagra | 50 (Typ.)(Tr+Td) ms |
| radharc maith ag | 12 o'clock |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 262K 50% NTSC |
| cúlsolas | WLED , 20K hours , With LED Driver |
| mais | - |
| a úsáidtear le haghaidh | Industrial |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | 4-wire Resistive Touch |
| cineál comhartha | Parallel RGB (1 ch, 6-bit) , Connector 40 pins |
| soláthar voltais | 3.3/5.0V (Typ.)(VCC/VDD) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
