| Uimhir Pháirt | AM-640480G2TNQW-A0H |
| Branda | AMPIRE |
| Méid | 5.7 |
| Iarratas | Industrial |
| Rún | 640×480 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 250:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | AMPIRE |
| Mionsamhail | AM-640480G2TNQW-A0H |
| méid trasnánach | 5.7 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 640(RGB)×480 [VGA] 141PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 115.2(H)×86.4(V) mm |
| imlíne dim. | 127(H)×98.43(V) ×7.8(D) mm |
| limistéar bezel | 118.0(H)×89.2(V) mm |
| cóireáil | Antiglare, Hard coating (3H) |
| luminance | 500 cd/m² (Typ.) |
| cóimheas codarsnachta | 250:1 (Typ.) (TM) |
| treo amharc | 12 o'clock |
| am freagartha | 50 (Typ.)(Tr+Td) |
| uillinn féachana | 70/70/50/50 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 262K 50% NTSC |
| foinse solais | WLED , 20K hours , With LED Driver |
| meáchan | - |
| deartha le haghaidh | Industrial |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 6-bit) , 20 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
