| Uimhir Pháirt | AM-480272METMQW-00H |
| Branda | AMPIRE |
| Méid | 4.3 |
| Iarratas | Industrial |
| Rún | 480×272 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 500:1 |
| Dathanna | 16.7M |
| Cúlsolas | 6S2P |
| Comhéadan | Parallel |
| monaróir | AMPIRE |
| ainm samhail | AM-480272METMQW-00H |
| méid scáileáin | 4.3 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 480(RGB)×272 (WQVGA) 128PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 95.04 × 53.856 (H×V) |
| imlíne (mm) | 105.5 × 67.2 (H×V×D) |
| limistéar bezel (mm) | 99.0 × 56.86 (H×V) |
| cóireáil | Antiglare, Hard coating (3H) |
| luminance | 500 cd/m² (Typ.) |
| cóimheas codarsnachta | 500 : 1 (Typ.) (TM) |
| uillinn féachana | 70/70/50/70 (Typ.)(CR≥10) |
| freagra | 8/17 (Typ.)(Tr/Td) ms |
| radharc maith ag | 12 o'clock |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 16.7M |
| cúlsolas | 6S2P WLED , 25K hours , No Driver |
| mais | - |
| a úsáidtear le haghaidh | Industrial |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | Parallel RGB (1 ch, 8-bit) , FPC 40 pins |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
