| Uimhir Pháirt | AM-320240LQTZQW-50H |
| Branda | AMPIRE |
| Méid | 3.5 |
| Iarratas | Industrial Outdoor H |
| Rún | 320×240 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | 6S2P |
| Comhéadan | Parallel |
| branda painéil | AMPIRE |
| méid an phainéil | 3.5" |
| taifeach | 320(RGB)×240, QVGA, 115PPI |
| limistéar taispeána | 70.08(W)×52.56(H) mm |
| méid imlíne | 76.9(W)×63.9(H) ×3.45(D) mm |
| gile | 800 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 16.7M 60% NTSC |
| minicíocht | 60Hz |
| meáchan painéal | - |
| comhéadan comhartha | Parallel RGB (1 ch, 8-bit) + SPI , 50 pins FPC |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| múnla painéil | AM-320240LQTZQW-50H |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 72.88(W)×54.94(H) mm |
| dromchla | - |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| mód taispeána | Normally Black, Transmissive |
| am freagartha | 30 (Typ.)(Tr+Td) |
| cineál lampa | 6S2P WLED , 36K hours , Without Driver |
| scáileán tadhaill | Without |
| iarratas | Industrial Outdoor High Brightness Instruments & Meters |
