| Uimhir Pháirt | AM-240320GTZQW-02H |
| Branda | AMPIRE |
| Méid | 2.8 |
| Iarratas | Mobile Phone |
| Rún | 240×320 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 450:1 |
| Dathanna | 65K |
| Cúlsolas | WLED |
| Comhéadan | CPU/RGB/SPI |
| branda | AMPIRE |
| Mionsamhail | AM-240320GTZQW-02H |
| méid trasnánach | 2.8 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 240(RGB)×320 [QVGA] 141PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 43.2(H)×57.6(V) mm |
| imlíne dim. | 49(H)×67.5(V) ×4.9(D) mm |
| luminance | 280 cd/m² (Typ.) |
| cóimheas codarsnachta | 450:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 15/20 (Typ.)(Tr/Td) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| modh oibriúcháin | MVA, Normally Black, Transmissive |
| dath tacaíochta | 65K 69% NTSC |
| foinse solais | WLED [3S2P] , With LED Driver |
| meáchan | TBD |
| deartha le haghaidh | Mobile Phone |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | CPU/RGB/SPI , 40 pins FPC |
| soláthar leictreachas | 2.8V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AM-240320-022F | Other | 2.2 | 240×320 |
| AM-240320-024DT | Other | 2.4 | 240×320 |
| C0283QGLD-T | CMEL | 2.8 | 240×320 |
| ET028002DMU | EDT | 2.8 | 240×320 |
| F-55472GNFJ-SLW-AAN | Kyocera | 2.8 | 128×64 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LTV280QV-F02 | Samsung | 2.8 | 320×240 |
| TD028STEB1 | TPO | 2.8 | 240×320 |
| TFT240320-237-E | Other | 2.8 | 240×320 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
