| Uimhir Pháirt | AM-19201200FTZQW-00 |
| Branda | AMPIRE |
| Méid | 10.1 |
| Iarratas | Industrial |
| Rún | 1920×1200 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | eDP |
| branda painéil | AMPIRE |
| múnla painéil | AM-19201200FTZQW-00 |
| méid an phainéil | 10.1" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 1920(RGB)×1200, WUXGA, 224PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 216.806(W)×135.504(H) mm |
| oscailt bezel | - |
| méid imlíne | 227.72(W)×147.8(H) ×5.35(D) mm |
| dromchla | - |
| gile | 380 cd/m² (Typ.) |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| mód taispeána | AHVA, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 25 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 16.7M 50% NTSC |
| cineál lampa | WLED , 30K hours , With LED Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | - |
| iarratas | Industrial |
| comhéadan comhartha | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
