| Uimhir Pháirt | AM-19201200CTZQW-T01 |
| Branda | AMPIRE |
| Méid | 10.1 |
| Iarratas | Industrial Outdoor H |
| Rún | 1920×1200 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda | AMPIRE |
| Mionsamhail | AM-19201200CTZQW-T01 |
| méid trasnánach | 10.1 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1920(RGB)×1200 [WUXGA] 225PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 216.576(H)×135.36(V) mm |
| imlíne dim. | 244.8(H)×155.3(V) ×8.01(D) mm |
| luminance | 850 cd/m² (Typ.) |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 25 (Typ.)(Tr+Td) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| modh oibriúcháin | AHVA, Normally Black, Transmissive |
| dath tacaíochta | 16.7M 49% NTSC |
| foinse solais | WLED [7S6P] , 50K hours , W/O Driver |
| meáchan | - |
| deartha le haghaidh | Industrial Outdoor High Brightness |
| ráta fhráma | 60Hz |
| painéal tadhaill | PCAP |
| Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -20 ~ 65 °C |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| B101XTN01.1 | AUO | 10.1 | 1366×768 |
| CLAA101NB03A | CPT | 10.1 | 1024×600 |
| F101NWN7-0 | IVO | 10.1 | 1920×1200 |
| G101AGE-L01 | Innolux | 10.1 | 800×600 |
| LP101WH1-TLB5 | LG Display | 10.1 | 1366×768 |
| LP101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LTL101AL06-W02 | Samsung | 10.1 | 1280×800 |
| N101L6-L0D | Innolux | 10.1 | 1024×600 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
