| Uimhir Pháirt | AM-1280800W2TZQW-00H |
| Branda | AMPIRE |
| Méid | 10.1 |
| Iarratas | Industrial |
| Rún | 1280×800 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | 7S4P |
| Comhéadan | LVDS |
| monaróir | AMPIRE |
| méid scáileáin | 10.1 inch |
| uimhir picteilín | 1280(RGB)×800 (WXGA) 149PPI |
| limistéar gníomhach(mm) | 216.96 × 135.6 (H×V) |
| limistéar bezel (mm) | - |
| luminance | 1000 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| doimhneacht dath | 16.7M 44% NTSC |
| mais | 160g (Max.) |
| ráta athnuachana | 60Hz |
| cineál comhartha | LVDS (1 ch, 8-bit) , 40 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ainm samhail | AM-1280800W2TZQW-00H |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 231 × 154.4 × 7.9 (H×V×D) |
| cóireáil | Glare (Haze 0%), Hard coating (3H) |
| cóimheas codarsnachta | 800 : 1 (Typ.) (TM) |
| freagra | 25 (Typ.)(Tr+Td) ms |
| modh oibre | ADS, Normally Black, Transmissive |
| cúlsolas | 7S4P WLED , 50K hours , No Driver |
| a úsáidtear le haghaidh | Industrial |
| scáileán tadhaill | Without |
