| Uimhir Pháirt | AM-1024768V1TZQW-A0H |
| Branda | AMPIRE |
| Méid | 8.4 |
| Iarratas | Industrial |
| Rún | 1024×768 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | AMPIRE |
| Mionsamhail | AM-1024768V1TZQW-A0H |
| méid trasnánach | 8.4 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1024(RGB)×768 [XGA] 152PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 170.8(H)×128.1(V) mm |
| imlíne dim. | 203(H)×145.5(V) ×8(D) mm |
| limistéar bezel | 174.15(H)×131.2(V) mm |
| cóireáil | - |
| luminance | 1000 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 30 (Typ.)(Tr+Td) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| modh oibriúcháin | IPS, Normally Black, Transmissive |
| dath tacaíochta | 16.7M |
| foinse solais | WLED [6S6P] , 50K hours , With LED Driver |
| meáchan | - |
| deartha le haghaidh | Industrial |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 8-bit) , 20 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
