| Uimhir Pháirt | AM-1024768R7TNQW-T00H |
| Branda | AMPIRE |
| Méid | 12.1 |
| Iarratas | Industrial |
| Rún | 1024×768 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | 9S3P |
| Comhéadan | LVDS |
| branda painéil | AMPIRE |
| méid an phainéil | 12.1" |
| taifeach | 1024(RGB)×768, XGA, 105PPI |
| limistéar taispeána | 245.76(W)×184.32(H) mm |
| méid imlíne | 279(W)×209(H) ×11.2(D) mm |
| gile | 510 cd/m² (Typ.) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| radharc is fearr ar | - |
| dathanna a thaispeáint | 262K/16.7M |
| minicíocht | 60Hz |
| meáchan painéal | - |
| comhéadan comhartha | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| múnla painéil | AM-1024768R7TNQW-T00H |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | - |
| dromchla | - |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| mód taispeána | TN, Normally White, Transmissive |
| am freagartha | 16 (Typ.)(Tr+Td) |
| cineál lampa | 9S3P WLED , 50K hours , Without Driver |
| scáileán tadhaill | PCAP |
| iarratas | Industrial |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| B121EW08 V0 | AUO | 12.1 | 1280×800 |
| B121EW10 V1 | AUO | 12.1 | 1280×800 |
| G121I1-L01 | Innolux | 12.1 | 1280×800 |
| LB121S03-TL01 | LG Display | 12.1 | 800×600 |
| LTD121EXSS | TOSHIBA | 12.1 | 1280×800 |
| LTM12C278F | TOSHIBA | 12.1 | 800×600 |
| M121MNS1 R0 | IVO | 12.1 | 800×600 |
