| Uimhir Pháirt | AM-1024768FCTMQW-T00H |
| Branda | AMPIRE |
| Méid | 10.4 |
| Iarratas | Industrial |
| Rún | 1024×768 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1200:1 |
| Dathanna | 262K/16.2M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | AMPIRE |
| Mionsamhail | AM-1024768FCTMQW-T00H |
| méid trasnánach | 10.4 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1024(RGB)×768 [XGA] 123PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 210.4(H)×157.8(V) mm |
| imlíne dim. | 238.6(H)×175.8(V) mm |
| luminance | 280 cd/m² (Typ.) |
| cóimheas codarsnachta | 1200:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 14/11 (Typ.)(Tr/Td) |
| uillinn féachana | 88/88/88/88 (Typ.)(CR≥10) |
| modh oibriúcháin | Normally Black, Transmissive |
| dath tacaíochta | 262K/16.2M 57% NTSC |
| foinse solais | WLED , 30K hours , With LED Driver |
| meáchan | - |
| deartha le haghaidh | Industrial |
| ráta fhráma | 60Hz |
| painéal tadhaill | PCAP |
| cineál comhéadan | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| A104SN03 V0 | AUO | 10.4 | 800×600 |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| G104STN01.0 | AUO | 10.4 | 800×600 |
| G104VN01 V1 | AUO | 10.4 | 640×480 |
| G104X1-L01 | Innolux | 10.4 | 1024×768 |
| LT104AC36000 | TOSHIBA | 10.4 | 1024×768 |
| NL8060AC26-04 | NLT | 10.4 | 800×600 |
| NL8060BC26-27 | NLT | 10.4 | 800×600 |
