| Uimhir Pháirt | AM-1024600K7TMQW-T53H |
| Branda | AMPIRE |
| Méid | 7.0 |
| Iarratas | Industrial |
| Rún | 1024×600 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 700:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | 5S3P |
| Comhéadan | LVDS |
| branda painéil | AMPIRE |
| méid an phainéil | 7.0" |
| taifeach | 1024(RGB)×600, WSVGA, 169PPI |
| limistéar taispeána | 153.6(W)×90(H) mm |
| méid imlíne | 165.5(W)×104.44(H) ×11.93(D) mm |
| gile | 425 cd/m² (Typ.) |
| uillinn féachana | 75/75/70/75 (Typ.)(CR≥10) |
| radharc is fearr ar | 6 o'clock |
| dathanna a thaispeáint | 262K/16.7M |
| minicíocht | 60Hz |
| meáchan painéal | TBD |
| comhéadan comhartha | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| múnla painéil | AM-1024600K7TMQW-T53H |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | - |
| dromchla | - |
| cóimheas codarsnachta | 700:1 (Typ.) (TM) |
| mód taispeána | TN, Normally White, Transmissive |
| am freagartha | 20/20 (Typ.)(Tr/Td) |
| cineál lampa | 5S3P WLED , 50K hours , With LED Driver |
| scáileán tadhaill | PCAP |
| iarratas | Industrial |
