| Uimhir Pháirt | AC070MR11 |
| Branda | Mitsubishi |
| Méid | 7.0 |
| Iarratas | Industrial Outdoor H |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | 2 |
| Comhéadan | LVDS |
| branda painéil | Mitsubishi |
| méid an phainéil | 7.0" |
| taifeach | 800(RGB)×480, WVGA, 133PPI |
| limistéar taispeána | 152.4(W)×91.44(H) mm |
| méid imlíne | 169.8(W)×109.7(H) ×9.3(D) mm |
| gile | 1000 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 262K/16.7M |
| minicíocht | 60Hz |
| meáchan painéal | 185g (Typ.) |
| comhéadan comhartha | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C |
| múnla painéil | AC070MR11 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 154.4(W)×93.44(H) mm |
| dromchla | Antiglare, Hard coating (3H) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| mód taispeána | SWV, Normally Black, Transmissive |
| am freagartha | 15/15 (Typ.)(Tr/Td) |
| cineál lampa | 2 strings WLED , 50K hours , Without Driver |
| scáileán tadhaill | Without |
| iarratas | Industrial Outdoor High Brightness |
