| Uimhir Pháirt | AA106TA01DDE11 |
| Branda | Mitsubishi |
| Méid | 10.6 |
| Iarratas | Industrial Outdoor H |
| Rún | 1280×768 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda | Mitsubishi |
| Mionsamhail | AA106TA01DDE11 |
| méid trasnánach | 10.6 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1280(RGB)×768 [WXGA] 140PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 231.36(H)×138.816(V) mm |
| imlíne dim. | 250(H)×175(V) ×15.5(D) mm |
| limistéar bezel | - |
| cóireáil | Antiglare, Hard coating (3H) |
| luminance | 800 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 12/12 (Typ.)(Tr/Td) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| modh oibriúcháin | SWV, Normally Black, Transmissive |
| dath tacaíochta | 262K/16.7M 50% NTSC |
| foinse solais | WLED , 100K hours , With LED Driver |
| meáchan | 670g (Typ.) |
| deartha le haghaidh | Industrial Outdoor High Brightness |
| ráta fhráma | 60Hz |
| painéal tadhaill | PCAP |
| Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AA106TA01 | Mitsubishi | 10.6 | 1280×768 |
| LQ106K1LA01C | SHARP | 10.6 | 1280×768 |
| LQ106K1LA02 | SHARP | 10.6 | 1280×768 |
| LQ106K1LA05 | SHARP | 10.6 | 1280×768 |
| LTD106EWNN | TOSHIBA | 10.6 | 1280×768 |
| LTL106AL01-001 | Samsung | 10.6 | 1366×768 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| LTN106W1-L01 | Samsung | 10.6 | 1280×768 |
| LTN106W2-L01 | Samsung | 10.6 | 1280×768 |
