| Uimhir Pháirt | AA101TA12 |
| Branda | Mitsubishi |
| Méid | 10.1 |
| Iarratas | Industrial Outdoor H |
| Rún | 1280×800 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | 2 |
| Comhéadan | LVDS |
| branda painéil | Mitsubishi |
| méid an phainéil | 10.1" |
| taifeach | 1280(RGB)×800, WXGA, 149PPI |
| limistéar taispeána | 216.96(W)×135.6(H) mm |
| méid imlíne | 231(W)×153.5(H) ×9(D) mm |
| gile | 800 cd/m² (Typ.) |
| uillinn féachana | 88/88/88/88 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 262K/16.7M 50% NTSC |
| minicíocht | 60Hz |
| meáchan painéal | 310g |
| comhéadan comhartha | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -40 ~ 80 °C ; Storage Temp.: -40 ~ 80 °C |
| múnla painéil | AA101TA12 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 220.96(W)×139.6(H) mm |
| dromchla | Antiglare, Hard coating (3H) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| mód taispeána | SWV, Normally Black, Transmissive |
| am freagartha | 12/12 (Typ.)(Tr/Td) |
| cineál lampa | 2 strings WLED , 100K hours , Without Driver |
| scáileán tadhaill | Without |
| iarratas | Industrial Outdoor High Brightness |
