| Uimhir Pháirt | A030DN01 VC |
| Branda | AUO |
| Méid | 3.0 |
| Iarratas | DSC |
| Rún | 320×240 |
| Comhdhéanamh | LCM |
| Gile | 350 |
| CR | 300:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | Serial RGB |
| branda painéil | AUO |
| múnla painéil | A030DN01 VC |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 3.0 inch |
| taifeach | 320(RGB)×240 , QVGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 60×45 mm |
| imlíne | 70.2×51.4 mm |
| dromchla | Hard coating |
| gile | 350 cd/m² (Typ.) |
| cóimheas codarsnachta | 300:1 (Typ.) |
| dathanna a thaispeáint | 16.7M (8-bit) |
| am freagartha | 10/25 (Typ.)(Tr/Td) |
| uillinn féachana | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 3S1PWLEDWithout Driver |
| comhéadan comhartha | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| voltas ionchuir | 3.3/15/-10V (Typ.)(VDD/VGH/VGL) |
| iarratas | DSC |
